Cisco WAP125 Administrator's Guide

◦ Static IP — Manually configure the IPv4 address. The IPv4 address should be in a form similar to
xxx.xxx.xxx.xxx (172.17.144.170).
• Static IP Address, Subnet Mask, and Default Gateway —Enter the static IP address, subnet mask and default
gateway.
• Domain Name Servers — Select one of the following options:
◦ Dynamic — The WAP device acquires the DNS server addresses from a DHCP server on the LAN.
◦ Manual — Enter up to two IP addresses in the fields provided.
Step 3
Click Save to save the changes.
DHCP Auto Configuration Settings
• DHCP Auto Configuration Options— This option is enabled by default. When AP comes up with
factory defaults, it first tries to auto configure using DHCP options.
During Auto Configuration:
◦
AP boots up with only Ethernet interface enabled and WLAN interfaces down.
◦
No services are available to User (except User Interfaces).
◦
DHCP Auto Configuration Options is disabled automatically after Wait Interval or TFTP upload
of Configuration file whichever is earlier.
◦
Disabling the DHCP client (i.e., configure use a static IP address) or disabling DHCP Auto
Configuration Options immediately aborts Auto configuration.
DHCP client automatically broadcasts requests for DHCP options 66 and 67. If DHCP and DHCP Auto
Configuration Options are enabled, Access Point is Auto configured during next reboot considering the
information received from DHCP Server for DHCP requests.
Configuration upload operation by User/Cisco overrides the Auto Configuration so that the chosen
configuration file is given preference. In any other cases of rebooting the AP such as firmware upgrade
or reboot operations, existing Auto Configuration settings will be effective.
Note
• TFTP Server IPv4 Address/Host Name—If you configure TFTP server address, it is used in case of
failure to retrieve file from other TFTP Servers specified by DHCP server during Auto Configuration.
Enter IPv4 address or hostname information. If it happens to be in hostname format DNS server must
be available to translate hostname into IP address.
The value is used during the Auto Configuration procedure during next boot-up.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
10
System Configuration
DHCP Auto Configuration Settings

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
