Cisco WAP125 Administrator's Guide

• IPv6 Autoconfigured Global Addresses — Lists the IPv6 addresses which have been automatically assigned to
the device.
• IPv6 Link Local Address — The IPv6 address used by the local physical link. The link local address is not
configurable and is assigned by using the IPv6 Neighbor Discovery process.
• Default IPv6 Gateway —The statically configured default IPv6 gateway.
• IPv6 Domain Name Servers — Select one of the following options:
◦ Dynamic — The DNS servers are recognized dynamically through the DHCPv6.
◦ Manual — To manually specify up to two IPv6 DNS servers.
Port Settings Table
Use the Port Settings Table to view and configure the settings for the port that connects the WAP device to
a LAN.
Step 1
Select LAN > More > Port Settings Table.
The Port Settings Table displays the following status and configurations for the LAN interface:
• Link Status — Displays the current port link status.
• Port Speed — When in review mode, it lists the current port speed. When in edit mode, and the Auto Negotiation
is disabled, select a port speed such as 100 Mbps or 10 Mbps. The 1000 Mbps speed is the only supported when
Auto-Negotiation is enabled.
• Duplex Mode —When in review mode, it lists the current port duplex mode. When in edit mode, and the Auto
Negotiation is disabled, select either Half or Full duplex mode.
• Auto Negotiation — When enabled, the port negotiates with its link partner to set the fastest link speed and duplex
mode available. When disabled, you can manually configure the Port Speed and Duplex Mode.
• Green Ethernet — Green Ethernet Mode supports both the auto-power-down mode and the EEE (Energy Efficient
Ethernet, IEEE 802.3az) mode. The Green Ethernet Mode works only when the auto-negotiation on the port is
enabled. The auto-power-down mode reduces the chip power when the signal from a link partner is not present.
The WAP device automatically enters into a low-power mode when energy on the line is lost, and it resumes normal
operation when energy is detected. The EEE mode supports QUIET times during low link utilization, allowing
both sides of a link to disable portions of each PHY’s operating circuit and save power.
Step 2
Click Save.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
12
System Configuration
Port Settings Table

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
