Cisco WAP125 Administrator's Guide

Guest Group Table
On the device, each local user is assigned to a user group and the group is assigned to a CP instance. The
group facilitates managing the assignment of users to CP instances.
The user group named Default is built-in and cannot be deleted.
To configure a local user:
Step 1
Select Guest Access > Guest Group Table.
Step 2
In the Guest Groups Settings area, configure the following parameters:
• Guest Group Name — Specify the name for the new guest group. The default Guest Group Name is Default
Step 3
Configure these parameters:
• Idle Timeout — Enter the period of time that a user remains in the CP authenticated client list after the client
disassociates from the WAP device. If the time specified in this field expires before the client attempts to
re-authenticate, the client entry is removed from the authenticated client list. The range is from 0 to 1440 minutes.
The default value is 60. The timeout value configured here has precedence over the value configured for the CP
instance, unless the user value is set to 0. When it is set to 0, the timeout value configured for the CP instance is
used.
• Maximum Bandwidth Up — Enter the maximum upload speed, in megabits per second, that a client can transmit
traffic when using the Captive Portal. This setting limits the bandwidth used to send data into the network. The
range is from 0 to 866 Mbps. The default is 0.
• Maximum Bandwidth Down — Enter the maximum download speed, in megabits per second, that a client can
receive traffic when using the Captive Portal. This setting limits the bandwidth used to receive data from the
network. The range is from 0 to 866 Mbps. The default is 0.
• Total Guest Users — Displays the number of total guest users. Click the value link on the Total Guest Users to
display the Guest User Account page.
Step 4
Click Save.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
83
Access Control
Guest Group Table

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
