Cisco WAP125 Administrator's Guide

Enabling persistent logging can wear out the flash (nonvolatile) memory and degrade network performance.
Only enable persistent logging to debug a problem. Make sure that you disable persistent logging after
you finish debugging the problem.
Caution
Configuring the Persistent Log
Step 1
Select Notification > Log Settings.
Step 2
Configure these parameters:
• Persistence — Check Enable to save system logs to the nonvolatile memory so that the logs are kept when the
WAP device reboots. You can save up to 1000 log messages. When the limit of 1000 is reached, the oldest log
message is overwritten by the newest message. Clear this field to save system logs to volatile memory. Logs in
volatile memory are deleted when the system reboots.
• Severity — Select the severity from the drop-down list (Emergency, Alert, Critical, Error, Warning, Notice,
Info or Debug) used to filter the event messages that will be saved in the nonvolatile memory. All other messages
will be saved in the volatile memory.
• Depth — Enter the maximum number of messages, up to 1000, that can be stored in volatile memory. When the
number that you configure in this field is reached, the oldest log event is overwritten by the newest log event.
Step 3
Click Save.
Remote Log Server
The kernel log is a comprehensive list of system events (shown in the System Log) and kernel messages.
You cannot view the kernel log messages directly from the configuration utility. You must first set up a remote
log server to receive and capture the logs. Then, you can configure the WAP device to log to the remote log
server. The WAP device supports up to two remote log servers.
The remote log server collection for the syslog messages provides these features:
•
Allows aggregation of syslog messages from multiple APs.
•
Stores a longer history of messages than is kept on a single WAP device.
•
Triggers scripted management operations and alerts.
To specify a host on your network to serve as a remote log server:
Step 1
Select Notification > Log Settings.
Step 2
In the Remote Log Server Table, configure the following parameters:
• Server IPv4/IPv6 Address/Name — Enter the IPv4 or IPv6 address, or the host name of the remote log server.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
18
System Configuration
Remote Log Server

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
