Cisco WAP125 Administrator's Guide

Spanning Tree Protocol
In the Spanning Tree Protocol mode, check Enable checkbox to enable the STP mode on the Cisco WAP
device. When enabled, STP helps prevent switching loops. STP is recommended if you configure WDS links.
VLANs Setting
Use the VLAN Configuration page to view and configure the VLANs settings.
Step 1
Select LAN > More > VLANs Setting Table.
Step 2
Configure these parameters:
• Untagged VLAN ID — Specifies a number between 1 and 4094 for the untagged VLAN ID. The default is 1. The
traffic on the VLAN that you specify in this field is not be tagged with a VLAN ID when forwarded to the network.
• Description — Description of the related VLAN.
• Management VLAN — The Management VLAN is the VLAN used to access the WAP device through Telnet
or the web GUI. There must be only one VLAN as the management VLAN. If no interface (wire or wireless) is
assigned to the Management VLAN, there will be no interface that a user can use to access the configuration utility.
• VLAN — Select from the drop-down list (Untagged or Tagged) VLAN.
By default, all traffic on the WAP device uses the VLAN 1, the default untagged VLAN. This means that all traffic
is untagged until you disable the untagged VLAN, change the untagged traffic VLAN ID, or change the VLAN
ID for a VAP or client using RADIUS.
Step 3
Click Save. The changes are saved to the Startup Configuration.
Neighbor Discover
Bonjour enables the WAP device and its services to be discovered by using multicast DNS (mDNS). Bonjour
advertises services to the network and answers queries for the service types that it supports, simplifying
network configuration in your environments.
The WAP device advertises these service types:
• Cisco-specific device description (csco-sb) — This service enables clients to discover the Cisco WAP
devices and other products deployed in your networks.
• Management user interfaces — This service identifies the management interfaces available on the
WAP device (HTTP and SNMP).
When a Bonjour-enabled WAP device is attached to a network, any Bonjour client can discover and get access
to the configuration utility without prior configuration.
A system administrator can use an installed Internet Explorer plug-in to discover the WAP device. The
web-based Configuration Utility shows up as a tab in the browser.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
13
System Configuration
Spanning Tree Protocol

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
