Cisco WAP125 Administrator's Guide

CHAPTER 8
Administration
This chapter describes how to configure the Administration settings and perform the diagnostics. It contains
the following topics:
•
Firmware, page 93
•
Configuration Files, page 95
•
Reboot, page 98
Firmware
The WAP device maintains two firmware images. One image is active and the other is inactive. If the active
image fails to load during boot up, the inactive image is loaded and becomes the active image. You can also
swap the active and inactive images.
When new versions of the firmware become available, you can upgrade the firmware on your WAP device
to take advantage of new features and enhancements. The WAP device uses a TFTP or HTTP/HTTPS client
for firmware upgrades.
After you upload the new firmware and the system reboots, the newly added firmware becomes the primary
image. If the upgrade fails, the original firmware remains as the primary image.
When you upgrade the firmware, the WAP device retains the existing configuration settings.Note
Swapping the Firmware Image
To swap the firmware image running on the WAP device:
Step 1
Select Administration > Firmware.
The product ID (PID VID) and active and inactive firmware versions are displayed.
Step 2
Click Swap Images.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
93

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
