Cisco WAP125 Administrator's Guide

• Destination Port — Includes a destination port in the match condition for the rule. The destination port is identified
in the datagram header.
◦ Any — Any port is allowed as the destination port.
◦ Select From List — Matches a keyword associated with the source port: ftp, ftpdata, http, smtp, snmp, telnet,
tftp, www. Each of these keywords translates into its equivalent port number.
◦ Custom — Matches the source port number in the datagram header to an IANA port number that you specify.
The port range is from 0 to 65535 and includes three different types of ports:
◦ 0 to 1023 — Well-Known Ports
◦ 1024 to 49151 — Registered Ports
◦ 49152 to 65535 — Dynamic and/or Private Port
• IPv6 Flow Label — The Flow Label is used by a node to label packets in a flow.
◦ Any — Any 20-bit number that is unique to an IPv6 packet.
◦ User Defined — Enter a 20-bit number that is unique to an IPv6 packet. It is used by end stations to signify
QoS handling in routers (range 0 to FFFFF).
• Service Type — Specifies the type of service to use in matching the packets to the class criteria.
◦ Any — Allows for any type of service as a match criterion.
◦ IP DSCP Select from List — Choose a DSCP value to use as a match criterion.
◦ IP DSCP Match to Value — Enter a custom DSCP value from 0 to 63
Step 7
Click OK. The changes are saved to the Startup Configuration.
To delete or modify a class map, select the Class Map Name from the list and click Delete. The class map cannot
be deleted if it is already attached to a policy.
Note
Step 8
Click Save.
Configuring MAC Traffic Classes
To add and configure a MAC class map:
Step 1
Select Client QoS > Traffic Classes.
Step 2
Click ✚ to add a Traffic Class.
The maximum number of class maps is
50.
Note
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
77
Access Control
Configuring MAC Traffic Classes

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
