Cisco WAP125 Administrator's Guide

◦ 49152 to 65535 — Dynamic and/or private port
• Flow Label — Specifies a 20-bit number that is unique to an IPv6 packet.
◦ Any — Any 20- bit number.
◦ DSCP — Matches the number based on a custom DSCP value.
• DSCP— Matches the packets based on their IP DSCP value.
◦ Any — Allows for any DSCP value.
◦ Select From List — Select a DSCP value from the drop down list.
◦ Custom — Enter a custom DSCP value, from 0 to 63.
Step 7
Click OK. The changes are saved to the Startup Configuration.
To delete or modify an ACL, select the ACL and then click Delete or Edit.
To delete or modify a rule, select the rule in the Rule Configuration area and click Delete or
Edit.
Note
Step 8
Click Save.
Configure MAC ACLs
To configure a MAC ACL:
Step 1
Select Access Control > ACL.
Step 2
Click ✚ to add a MAC ACL.
Step 3
In the ACL Name field, enter the name to identify the ACL.
Step 4
Choose MAC as the type of ACL from the list. MAC ACLs control access based on Layer 2 criteria.
Step 5
Click ✚ and select the associated interfaces to apply the ACL and click OK. If you want to change the associated
interfaces, you can click ━ to delete the selected interface and then click ✚ to choose new associated interfaces.
Step 6
Then, click More to view the configuration parameters. Click ✚ to add a rule and configure the following parameters:
• Rule Priority — When an ACL has multiple rules, the rules are applied to the packet or frame in the order of their
priorities. Smaller number means higher priority. The priority of the new rule will be the lowest of all explicit rules
and you can click the up or down button to change its priority. Note that there is always an implicit rule denying
all traffic with lowest priority.
• Action — Choose whether to Deny or Permit the action. The default action is Deny.
When you choose Permit, the rule allows all traffic that meets the rule criteria to enter the WAP device. Traffic
that does not meet the criteria is dropped.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
71
Access Control
Configure MAC ACLs

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
