Deployment Models
• The WRP500 connects the computers to the Internet. Computers may be connected by network
cables or may operate wirelessly. All computers have access to the printer on the local network.
• An analog phone and a fax machine are connected to the WRP500 phone ports and have access to
the configured Voice over IP services.
WRP500 Deployment with a Wireless Guest Network
In this example, the WRP500 is deployed in an Internet cafe.
• The WRP500 is connected to a cable modem that provides Internet access.
Note The WRP500 may be configured as an edge device or can be connected to another device
that provides access to the Service Provider network.
Internet Access
Device
Wireless Guest Network
Personal
computer
WRP400
Laptop
computer
Analog phone
Fax
Printer
Private Network
Internet
194232
