Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
B-21
Cisco WRP500 Administration Guide
Appendix B Data Fields
Applications and Gaming
Applications & Gaming > Port Range Triggering
Applications & Gaming > DMZ
Applications and Gaming > QoS (Quality of Service)
Application Name The application name of the trigger.
Triggered Range The starting and ending port numbers of the triggered
port number range.
Forwarded Range The starting and ending port numbers of the forwarded
port number range.
Enabled/Disabled To disable DMZ hosting, select Disabled. To expose
one PC, select Enabled. Then configure the Source IP
Address and Destination.
Source IP Address Select Any IP Address, or specify an IP address or
range of IP addresses as the designated source.
Destination If you want to specify the DMZ host by IP address,
select IP Address and enter the IP address in the field
provided. If you want to specify the DMZ host by
MAC address, select MAC Address and enter the
MAC address in the field provided.
Wireless
WMM Support To support Wi-Fi Multimedia (WMM) on your
network, select Enabled.
Default: Disabled
No Acknowledgement To prevent the WRP500 from resending data if an error
occurs, select Enabled.
Default: Disabled
Internet Access Priority
Enabled/Disabled To use the QoS policies you have set, keep the default,
Enabled. Otherwise, select Disabled.
Upstream Bandwidth To allow the WRP500 to control the maximum
bandwidth for upstream data transmissions, keep the
default, Auto. To manually set the maximum, select
Manual, and enter the appropriate number in the field
provided.
