Cisco WRP500 Administration Guide
Appendix B Data Fields
Status
Status > Router
Status > Mobile Network
Router Information
Firmware Version The version number of the current firmware is
displayed.
Current Time The time set on the WRP500 is displayed.
Internet MAC Address The MAC address, as seen by your service provider, is
displayed.
Router Name The name of the WRP500 is displayed.
Host Name If required by your service provider, this was entered
on the Basic Setup screen.
Domain Name If required by your service provider, this was entered
on the Basic Setup screen.
Internet Connection
Connection Type
The type of Internet connection: Automatic Configuration
- DHCP, Static IP, PPPoE, PPTP, L2TP, Telstra Cable
Internet IP Address The IP address of your WRP500, as seen from the
Internet.
Subnet Mask The subnet mask, as seen by users on the Internet
Default Gateway The IP address of your service provider server.
DNS1, DNS2, DNS3 The addresses of the Domain Name Servers (DNS)
servers for your Service Provider.
MTU
Maximum Transmission Unit. The largest packet size that
is permitted for Internet transmission. Can be set manually
or automatically.
Mobile Network Status
Connection The status of the mobile network connection, either
Disconnected or Connected.
Connection Up Time The period of time that the Mobile USB modem has
been connected to the Internet during this session.
Current Session Usage The number of packets have been downloaded and
uploaded during this session.
Data Card Status
Manufacturer The manufacturer of the Mobile USB modem data
card.
