REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-10
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
SIP page
Voice tab > SIP page >
RTP Parameters section
Voice tab > SIP page >
SDP Payload Types section
Retry Reg RSC Interval to wait before the WRP500 retries registration after failing
during the last registration.
The default is 30.
RTP Port Min Minimum port number for RTP transmission and reception. The RTP
Port Min and RTP Port Max parameters should define a range that
contains at least 4 even number ports, such as 100 – 106.
The default is 16384.
RTP Port Max Maximum port number for RTP transmission and reception.
The default is 16482.
RTP Packet Size Packet size in seconds, which can range from 0.01 to 0.16. Valid
values must be a multiple of 0.01 seconds.
The default is 0.030.
Stats In BYE Determines whether the WRP500 includes the P-RTP-Stat header
or response to a BYE message. The header contains the RTP
statistics of the current call. Select yes or no from the drop-down
menu. The format of the P-RTP-Stat header is:
P-R
TP-State: PS=<packets sent>
,OS=<octets sent>,PR=<packets received>,OR=<octets received>,PL=<packets lost>,JI=<jitter in
ms>,LA=<delay in ms>,DU=<call duration in
s>,EN=<encoder>,DE=<decoder>.
The default is no.
NSE Dynamic
Payload
NSE dynamic payload type. The valid range is 96-127.
The default is 100.
AV T D y n a m i c
Payload
AVT dynamic payload type. The valid range is 96-127.
The default is 101.
