Page #47 background image
REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-3
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Info page
Voice tab > Info page >
Line Status section
SIP Bytes Recv Total number of bytes of SIP messages received (including
retransmissions).
External IP External IP address used for NAT mapping.
Hook State Hook state of the FXO port. Options are either On or Off.
Registration State Indicates if the line has registered with the SIP proxy.
Last Registration At Last date and time the line was registered.
Next Registration In Number of seconds before the next registration renewal.
Message Waiting Indicates whether you have new voice mail waiting. Options are
either Yes or No. The value automatically is set to Yes when a
message is received. You also can clear or set the flag manually.
Setting this value to Yes can activate stutter tone and VMWI signal.
This parameter is stored in long term memory and survives after
reboot or power cycle.
Call Back Active Indicates whether a call back request is in progress. Options are
either Yes or No.
Last Called Number The last number called from the FXO Line.
Last Caller Number Number of the last caller.
Mapped SIP Port Port number of the SIP port mapped by NAT.
Call 1 and 2 State May take one of the following values:
•Idle
Collecting PSTN Pin
Invalid PSTN PIN
PSTN Caller Accepted
Connected to PSTN
Call 1 and 2 Tone Type of tone used by the call.
Call 1 and 2 Encoder Codec used for encoding.
Call 1 and 2 Decoder Codec used for decoding.
Call 1 and 2 FAX Status of the fax pass-through mode.
