Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-27
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Regional page
Voice tab > Regional page >
Miscellaneous section
Set Local Date (mm/dd) Sets the local date (mm stands for months and dd stands for days). The
year is optional and uses two or four digits.
Set Local Time
(HH/mm)
Sets the local time (hh stands for hours and mm stands for minutes).
Seconds are optional.
FXS Port Impedance Sets the electrical impedance of the FXS port. Choices are 600, 900,
600+2.16uF, 900+2.16uF, 270+750||150nF, 220+850||120nF,
220+820||115nF, or 200+600||100nF.
The default is 600.
FXS Port Input Gain Input gain in dB, up to three decimal places. The range is 6.000 to
-12.000.
The default is -3.
FXS Port Output Gain Output gain in dB, up to three decimal places. The range is 6.000 to
-12.000. The Call Progress Tones and DTMF playback level are not
affected by the FXS Port Output Gain parameter.
The default is -3.
DTMF Playback Level Local DTMF playback level in dBm, up to one decimal place.
The default is -16.0.
DTMF Playback
Length
Local DTMF playback duration in milliseconds.
The default is .1.
DTMF Playback Twist Local DTMF playback duration.
The default is 1.3.
