Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-2
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Info page
Voice tab > Info page >
Product Information section
Voice tab > Info page >
System Status section
Product Name Model number/name.
Serial Number Serial number.
Software Version Software version number.
Hardware Version Hardware version number.
MAC Address MAC address.
Client Certificate Status of the client certificate, which can indicate if the WRP500
has been authorized by your ITSP.
Customization For a Remote Configuration (RC) unit, this field indicates whether
the unit has been customized or not. Pending indicates a new RC
unit that is ready for provisioning. If the unit has already retrieved
its customized profile, this field displays the name of the company
that provisioned the unit.
Voice Module Version Voice module number
Current Time Current date and time of the system; for example, 10/3/2003
16:43:00.
Elapsed Time Total time elapsed since the last reboot of the system; for example,
25 days and 18:12:36.
RTP Packets Sent Total number of RTP packets sent (including redundant packets).
RTP Bytes Sent Total number of RTP bytes sent.
RTP Packets Recv Total number of RTP packets received (including redundant
packets).
RTP Bytes Recv Total number of RTP bytes received.
SIP Messages Sent Total number of SIP messages sent (including retransmissions).
SIP Bytes Sent Total number of bytes of SIP messages sent (including
retransmissions).
SIP Messages Recv Total number of SIP messages received (including retransmissions).
