REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-36
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Line page
Voice tab > Line page >
Subscriber Information section
Proxy Fallback Intvl
This parameter sets the delay (sec) after which the WRP500 will
retry from the highest priority proxy (or outbound proxy) servers
after it has failed over to a lower priority server. This parameter is
useful only if the primary and backup proxy server list is provided
to the WRP500 via DNS SRV record lookup on the server name.
(Using multiple DNS A record per server name does not allow the
notion of priority and so all hosts will be considered at the same
priority and the WRP500 will not attempt to fall back after a fail
over).
The default is 3600
Proxy Redundancy
Method
The WRP500 will make an internal list of proxies returned in DNS
SRV records. In normal mode, this list will contain proxies ranked
by weight and priority.
if Based on SRV port is configured the WRP500 does normal first,
and also inspect the port number based on 1st proxy’s port on the
list.
The default is Normal.
Voice Mail Server
Enter the URL or IP address of the server.
Mailbox Subscribe
Expires
Expiry time to the voice mail server. The time to send another
subscribe message to the voice mail server.
Display Name
Display name for caller ID.
User ID
Extension number for this line.
Password
Password for this line.
Use Auth ID
To use the authentication ID and password for SIP authentication,
select yes. Otherwise, select no to use the user ID and password.
The default is no.
Auth ID
Authentication ID for SIP authentication.
Directory Number
Enter the number for this line.
Call Capacity
Maximum number of calls allowed on this line interface. Choices:
{unlimited,1,2,3,…25 }. Default is 16. Note that the the WRP500
does not distinguish between incoming and outgoing calls when
talking about call capacity.
NOTE: unlimited = 16
