Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-4
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Info page
Call 1 and 2 Type Direction of the call. May take one of the following values:
• PSTN Gateway Call = VoIP-To-PSTN Call
• VoIP Gateway Call = PSTN-To-VoIP Call
• PSTN To Line 1 = PSTN call ring through and answered by Line 1
• Line 1 Forward to PSTN Gateway = VoIP calls Line 1 then forwarded
to PSTN GW
• Line 1 Forward to PSTN Number =VoIP calls Line 1 then forwarded
to PSTN number
• Line 1 To PSTN Gateway
• Line 1 Fallback To PSTN Gateway
Call 1 and 2 Remote
Hold
Indicates whether the far end has placed the call on hold.
Call 1 and 2 Callback Indicates whether the call was triggered by a call back request.
Call 1 and 2 Peer
Name
Name of the internal phone.
Call 1 and 2 Peer
Phone
Phone number of the internal phone.
Call 1 and 2 Call
Duration
Duration of the call.
Call 1 and 2 Packets
Sent
Number of packets sent.
Call 1 and 2 Packets
Recv
Number of packets received.
Call 1 and 2 Bytes
Sent
Number of bytes sent.
Call 1 and 2 Bytes
Recv
Number of bytes received.
Call 1 and 2 Decode
Latency
Number of milliseconds for decoder latency.
Call 1 and 2 Jitter Number of milliseconds for receiver jitter.
Call 1 and 2 Packets
Lost
Number of packets lost.
Call 1 and 2 Packet
Error
Number of invalid packets received.
Call 1 and 2 Mapped
RTP Port
The port mapped for Real Time Protocol traffic for Call 1/2.
Call 1 and 2 Media
Loopback
Media loopback is used to quantitatively and qualitatively measure
the voice quality experienced by the end user.
