Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-33
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
Line page
SIP Debug Option SIP messages are received at or sent from the proxy listen port. This
feature controls which SIP messages to log. Choices are as follows:
• none—No logging.
• 1-line—Logs the start-line only for all messages.
• 1-line excl. OPT—Logs the start-line only for all messages except
OPTIONS requests/responses.
• 1-line excl. NTFY—Logs the start-line only for all messages except
NOTIFY requests/responses.
•1-line excl. REG—Logs the start-line only for all messages except
REGISTER requests/responses.
• 1-line excl. OPT|NTFY|REG—Logs the start-line only for all
messages except OPTIONS, NOTIFY, and REGISTER
requests/responses.
• full—Logs all SIP messages in full text.
• full excl. OPT—Logs all SIP messages in full text except OPTIONS
requests/responses.
• full excl. NTFY—Logs all SIP messages in full text except NOTIFY
requests/responses.
• full excl. REG—Logs all SIP messages in full text except REGISTER
requests/responses.
• full excl. OPT|NTFY|REG—Logs all SIP messages in full text
except for OPTIONS, NOTIFY, and REGISTER requests/responses.
• The default is none.
RTP Log Intvl The interval for the RTP log.
Restrict Source IP
If Lines 1 and 2 use the same SIP Port value and the Restrict Source
IP feature is enabled, the proxy IP address for Lines 1 and 2 is
treated as an acceptable IP address for both lines. To enable the
Restrict Source IP feature, select yes. Otherwise, select no. If
configured, the WRP500 will drop all packets sent to its SIP Ports
originated from an untrusted IP address. A source IP address is
untrusted if it does not match any of the IP addresses resolved from
the configured Proxy (or Outbound Proxy if Use Outbound Proxy is
yes).
The default is no.
Referor Bye Delay
Controls when the WRP500 sends BYE to terminate stale call legs
upon completion of call transfers. Multiple delay settings (Referor,
Refer Target, Referee, and Refer-To Target) are configured on this
screen. For the Referor Bye Delay, enter the appropriate period of
time in seconds.
The default is 4.
