Cisco WRP500 Administration Guide

REVIEW DRAFT #1—CISCO CONFIDENTIAL
A-44
Cisco WRP500 Administration Guide
Appendix A Advanced Voice Fields
User page
DND Setting DND on or off.
The default is no.
CID Setting Caller ID Generation on or off.
The default is yes.
CWCID Setting Call Waiting Caller ID Generation on or off.
The default is yes.
Dist Ring Setting Distinctive Ring on or off.
The default is yes.
Secure Call Setting If yes, all outbound calls are secure calls by default.
The default is no.
Message Waiting This value is updated when there is voice mail notification received
by the WRP500. The user can also manually modify it to clear or
set the flag. Setting this value to yes can activate stutter tone and
VMWI signal. This parameter is stored in long term memory and
will survive after reboot or power cycle.
The default is no.
Accept Media
Loopback Request
Controls how to handle incoming requests for loopback operation.
Choices are: Never, Automatic, and Manual, where:
• never—never accepts loopback calls; reply 486 to the caller
• automatic—automatically accepts the call without ringing
• manual —rings the phone first, and the call must be picked up
manually before loopback starts.
The default is Automatic.
Media Loopback
Mode
The loopback mode to assume locally when making call to request
media loopback. Choices are: Source and Mirror. Default is
Source.
Note that if the WRP500 answers the call, the mode is determined
by the caller.
Media Loopback Type The loopback type to use when making call to request media
loopback operation. Choices are Media and Packet. Default is
Media.
Note that if the WRP500 answers the call, then the loopback type is
determined by the caller (the WRP500 always picks the first
loopback type in the offer if it contains multiple types.)
