12-34

Catalyst 3560 Switch Software Configuration Guide

78-16156-01

Chapter 12 Configuring VLANs

Configuring VMPS

Figure 12-5 Dynamic Port VLAN Membership Configuration

Primary VMPS

Server 1

Catalyst 6500 series

Secondary VMPS

Server 2

Catalyst 6500 series

Secondary VMPS

Server 3

172.20.26.150

172.20.26.151

Catalyst 6500 series switch A

172.20.26.152

Switch C

Ethernet segment

(Trunk link)

172.20.26.153

172.20.26.154

172.20.26.155

172.20.26.156

172.20.26.157

172.20.26.158

172.20.26.159

Client switch I

Client switch B

End

station 2

End

station 1

TFTP server

Dynamic-access port

Switch J

Switch D

Switch E

Switch F

Switch G

Switch H

172.20.22.7

101363t

Trunk port

Router
