Catalyst 3560 Switch Software Configuration Guide
78-16156-01
Chapter 1 Overview
Network Configuration Examples
Network Configuration Examples
This section provides network configuration concepts and includes examples of using the switch to
create dedicated network segments and interconnecting the segments through Fast Ethernet and Gigabit
Ethernet connections.
• “Design Concepts for Using the Switch” section on page 1-11
• “Small to Medium-Sized Network Using Catalyst 3560 Switches” section on page 1-13
• “Large Network Using Catalyst 3560 Switches” section on page 1-14
• “Long-Distance, High-Bandwidth Transport Configuration” section on page 1-16
Design Concepts for Using the Switch
As your network users compete for network bandwidth, it takes longer to send and receive data. When
you configure your network, consider the bandwidth required by your network users and the relative
priority of the network applications they use.
Table 1-2 describes what can cause network performance to degrade and how you can configure your
network to increase the bandwidth available to your network users.
RMON Disabled Chapter 24, “Configuring RMON”
Syslog messages Enabled; displayed on the console Chapter 25, “Configuring System Message
Logging”
SNMP Enabled; version 1 Chapter 26, “Configuring SNMP”
ACLs None configured Chapter 27, “Configuring Network
Security with ACLs”
QoS Disabled Chapter 28, “Configuring QoS”
EtherChannels None configured Chapter 29, “Configuring EtherChannels”
Table 1-1 Default Settings After Initial Switch Configuration (continued)
Feature Default Setting More information in...
