31-4
Catalyst 3560 Switch Software Configuration Guide
78-16156-01
Chapter 31 Configuring HSRP
Configuring HSRP
Default HSRP Configuration
Table 31-1 shows the default HSRP configuration.
HSRP Configuration Guidelines
Follow these guidelines when configuring HSRP:
• HSRP can be configured on a maximum of 32 VLAN or routing interfaces.
• In the following procedures, the specified interface must be one of these Layer 3 interfaces:
–
Routed port: a physical port configured as a Layer 3 port by entering the no switchport
interface configuration command.
–
SVI: a VLAN interface created by using the interface vlan vlan_id global configuration
command and by default a Layer 3 interface.
–
Etherchannel port channel in Layer 3 mode: a port-channel logical interface created by using
the interface port-channel port-channel-number global configuration command and binding
the Ethernet interface into the channel group. For more information, see the “Configuring
Layer 3 EtherChannels” section on page 29-12.
• All Layer 3 interfaces must have IP addresses assigned to them. See the “Configuring Layer 3
Interfaces” section on page 10-19.
Table 31-1 Default HSRP Configuration
Feature Default Setting
HSRP groups None configured
Standby group number 0
Standby MAC address System assigned as: 0000.0c07.acXX, where XX is the HSRP
group number
Standby priority 100
Standby delay 0 (no delay)
Standby track interface priority 10
Standby hello time 3 seconds
Standby holdtime 10 seconds
