Chapter 1 Specifications
1-2. Printable Area
CL-E720DT 1-8
1-2. Printable Area
The printable area of the printer is as follows:
When media is set to the printer, aligned it with the media guide at the left of the “Unit Mechanism”.
Though the available maximum media width is 118 mm (4.65"), there are unprintable areas on
both sides: 2.5 mm (0.10") width on the left side and 11.5 mm (0.45") width on the right side.
The unprintable areas on both sides apply to any size media.
H R
104.0 mm (4.09”) 11.5 mm (0.45”)
Maximum media width: 118 mm (4.65")
H
R
Reference end
Unprintable area
Printable area
Media guide
Direction of media feed
2.5 mm (0.10")
(0, 0)
Printing start position
