Chapter 1 Specifications
1-1. General Specifications
1-3 CL-E720DT
1-1. General Specifications
Printing
Printing method Direct thermal
Main scanning line density: 203 dots/inch (8 dots/mm)
Sub-scanning line density: 203 dots/inch (8 dots/mm)
Resolution
Head: 864 dots (effective dots: 832 dots)
Max. print width 104 mm 4.1"
Max. print length 2539.7 mm 99.99"
Print density Print density is adjustable with software.
Printing speed setting 8, 7, 6, 5, 4, 3 or 2 inches per second
* At a printing speed of 8 or 7 inches per second, use density 10
and recommended thermal paper at normal temperature.
* 6, 5, 4, 3 or 2 inches per second when an optional peeler is used.
Print mode
Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is
completed.
Cut mode *
1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are available.
• Back feed • Cut through
(Cut through refers to stopping present printing to cut the previous
label when it reaches the cut position. After cutting, printing restarts
but a gap may be created at the seam of the printing at this time.)
Peel mode*
1
Peels labels from the liner after printing them.
Media
Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags, paper or tickets)
Recommended media label media (150LA-1 Ricoh), tag media (130LHB Ricoh)
Max. media width 118.0 mm 4.65"
Min. media width 19.5 mm 0.77"
Min. label width 19.5 mm 0.77"
Min. label pitch*
2
6.35 mm 0.25"
Max. media thickness 0.254 mm 0.01"
Max. media length 2539.7 mm 99.99”
Min. media length 6.40 mm 0.25"
Min. media thickness 0.0635 mm 0.0025"
*1: Options can be separately purchased.
*2: When a media pitch of less than 25.4 mm (1 inch) is used, set the “Small Media
Adjustment” setting in the “Page Setup” menu to “ON”.
