Chapter 4 Troubleshooting
4-1. Error Message and Corrective Actions
4-3 CL-E720DT
4-1. Error Message and Corrective Actions
When an error occurs, the error condition will be displayed on the operation panel. The LED
flashes in red and the LCD shows the error contents.
In case of an error, the printer enters off line except for the following errors.
• LCD: Alarm Head Hot
• LCD: Alarm Cutter Hot
• LCD: Alarm Head Check
Causes/Corrective Actions LED LCD
Head temperature - high temperature abnormality
Printing stops temporarily.
Wait until the “SA Head” gets cool.
Flashing in red Alarm
Head Hot
Head temperature - low temperature abnormality
• Printing is impossible.
Start printing after the “SA Head” becomes warm.
Flashing in red Error
Head Cold
PF motor temperature abnormality
• Printing is impossible.
Wait until the “SA PF Motor” gets cool.
Flashing in red Error
PFMotor Hot
Cutter motor temperature abnormality (Option)
Cutting action stops temporarily.
Wait until the cutter motor gets cool.
Flashing in red Alarm
Cutter Hot
Head open
Close the head.
Flashing in red Error
Head Open
Paper end
• Add media.
Flashing in red Error
Paper End
Paper out (paper position undetectable) - defective
paper loading
Incorrect positioning of the sensors:
Adjust the sensor position correctly to label media and
the black mark of tag media.
Incorrect setting of “Media Sensor” submenu:
Match the setting (See Through, Reflect, None) with
media to be used.
Incorrect sensor adjustment against media to be
used:
Enter sensor adjustment mode by turning ON while
pressing and holding [MENU], [FEED] ( ) and
[STOP] (
) keys. Then perform sensor adjustment.
For details, refer to “2-3-3(3) How to change the
settings in Factory mode” in Chapter 2.
Flashing in red Error
Paper Load
Paper jam
Remove the jammed media.
Flashing in red Error
Paper Jam
