Chapter 5 Parts Lists
CL-E720DT 5-12
PARTS LIST for CL-E720DT TITLE: Unit Base Sheet No. 2/2
Drawing No. 2 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
2-20 Screw BH M3.0x6 (NI) E00530-060WF 3
-21 Screw PH (SW+PW) M3x5 E04030-050F 4
-22 Screw NO2 FH M3.0x6 (NI) E00230-060WF 2
-23 Screw PH (SW+PW) M4x6 E00940-060F 1
-24 Screw BH M3.0x8 E00530-080F 4
To Next Page
