Citrix ADC MPX
10 VRMEFGH Temp | 40 degrees C | ok
11 DIMMABCD Temp | 27 degrees C | ok
12 DIMMEFGH Temp | 30 degrees C | ok
13 FAN1 | 9380 RPM | ok
14 FAN2 | 9380 RPM | ok
15 FAN3 | 9380 RPM | ok
16 FAN4 | 9240 RPM | ok
17 FAN5 | 9240 RPM | ok
18 FAN6 | 9240 RPM | ok
19 12V | 12.38 Volts | ok
20 5VCC | 5.12 Volts | ok
21 3.3VCC | 3.32 Volts | ok
22 VBAT | 3.06 Volts | ok
23 5VSB | 5.13 Volts | ok
24 3.3VSB | 3.39 Volts | ok
25 1.8V PCH | 1.85 Volts | ok
26 PVNN PCH | 1.03 Volts | ok
27 1.05V PCH | 1.06 Volts | ok
28 2.5V BMC | 2.56 Volts | ok
29 1.8V BMC | 1.78 Volts | ok
30 1.2V BMC | 1.18 Volts | ok
31 1.0V BMC | 0.99 Volts | ok
32 VcpuVRM | 1.78 Volts | ok
33 Vcpu | 1.07 Volts | ok
34 VDimmABCD | 1.22 Volts | ok
35 VDimmEFGH | 1.22 Volts | ok
36 PS1 Status | 0x01 | ok
37 PS2 Status | 0x00 | ok
38 root@ns#
39 <!--NeedCopy-->
LOM GUI
1. Log on to the LOM GUI.
2. On the Dashboard, click Sensor for temperature and voltage values. Click Fan for fan values.
