Citrix ADC MPX
The following componentsarevisible on the back panel of the MPX11500/13500/14500/16500/18500/20500
appliance:
• 160 GB or larger removable solid‑state drive.
Note: Drive densities might increase as components become EOL but its size is never smaller
than the original.
• USB port (reserved for a future release).
• Power switch, which turns o power to the appliance, as if you were to unplug the power supply.
Press the switch for five seconds to shut o the power.
• Non‑maskable interrupt (NMI) Button that is used at the request of Technical Support and pro‑
duces a core dump on the appliance. Use a pen, pencil, or other pointed object to press this red
button, which is recessed to prevent unintentional activation.
• Two removable hard‑disk drives that are used to store user data.
• Disable alarm button. This button is functional only when the appliance has two power sup‑
plies.
Press this button to stop the power alarm from sounding when either of the following conditions is
true:
1 - You have plugged the appliance into only one power outlet.
2 - One power supply is malfunctioning, and you want to continue
operating the appliance until it is repaired.
• Two power supplies, each rated at 960 watts, 110–220 volts. Maximum power consumption is
650 watts. Typical power consumption is 500 watts.
For information about installing the rails, rack mounting the hardware, and connecting the cables,
see Installing the Hardware.
For information about performing the initial configuration of your appliance, see Initial Configuration.
Citrix ADC MPX 11500
September 19, 2022
The Citrix ADC models
MPX 11515/11520/11530/11540/11542 are 2U appliances. Each model has two 6‑core processors for a
total of 12 physical cores (24 cores with hyper‑threading), and 48 GB of memory. The following figure
shows the front panel of the
MPX 11515/11520/11530/11540/11542 appliance.
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 48
