Citrix ADC MPX
Citrix ADC MPX 8005, MPX 8015, MPX 8200, MPX 8400, MPX 8600, and
MPX 8800
September 19, 2022
The Citrix ADC models
MPX 8005, MPX 8015, MPX 8200, MPX 8400,
MPX 8600, and MPX 8800 are 1U appliances. Each model has one quad‑core processor and 32 GB of
memory. The
MPX
8005/8015/8200/8400/8600
/8800 appliances are available in two port configurations:
• Six 10/100/1000Base‑T copper Ethernet ports and six 1G SFP ports (6x10/100/1000Base‑T cop‑
per Ethernet ports + 6x1G SFP)
• Six 10/100/1000Base‑T copper Ethernet ports and two 10G SFP+ ports (6x10/100/1000Base‑T
copper Ethernet ports + 2x10G SFP+)
The following figure shows the front panelof the MPX8005/8015/8200/8400/8600/8800 (6x10/100/1000Base‑
T copper Ethernet ports + 6x1G SFP) appliance.
Figure 1. Citrix ADC MPX 8005/8015/8200/8400/8600/8800 (6x10/100/1000Base‑T copper Ethernet
ports + 6x1G SFP), front panel
The following figure shows the front panelof the MPX8005/8015/8200/8400/8600/8800 (6x10/100/1000Base‑
T copper Ethernet ports + 2x10G SFP+) appliance.
Figure 2. Citrix ADC MPX 8005/8015/8200/8400/8600/8800 (6x10/100/1000Base‑T copper Ethernet
ports + 2x10G SFP+), front panel
