Citrix ADC MPX
Note: Earlier MPX 8005/8015/8200/8400/8600/8800 appliances had three extra SSD slots for fu‑
ture use. Current Citrix ADC MPX 8005/8015/8200/8400/8600/8800 appliances do not have any
additional SSD slots for future use.
• Power switch, which turns o power to the appliance, as if you were to unplug the power supply.
Press the switch for five seconds to shut o the power.
• USB port (reserved for a future release).
• Non‑maskable interrupt (NMI) button, which is used at the request of Technical Support to pro‑
duce a Citrix ADC core dump. Use a pen, pencil, or other pointed object to press this red button,
which is recessed to prevent unintentional activation.
• Disable alarm button, which is nonfunctional. This button is functional only if you install a
second power supply.
Press this button to stopthe power alarm from sounding when either of the following conditions
is true:
– You have plugged the appliance into only one power outlet.
– One power supply is malfunctioning, and you want to continue operating the appliance
until it is repaired.
• Single power supply, rated at 450 watts, 110–220 volts. Maximum power consumption is 250
watts and typical power consumption is 185 watts.
Note: The MPX 8005/8015/8200/8400/8600/8800 appliance supports dual power supplies, but ships
with one power supply. Contact your Citrix sales representative to order a second power supply.
For information about installing the rails, rack mounting the hardware, and connecting the cables,
see Hardware installation.
For information about performing the initial configuration of your appliance, see Citrix ADC initial
configuration.
Citrix ADC MPX 8900
September 19, 2022
The Citrix ADC MPX 8900 appliance is a 1U appliance. This platform has a single 8‑core processor and
32 GB of memory. The appliance provides a total of 10 network ports:
• Six 10/100/1000Base‑T RJ45 copper Ethernet Ports.
• Four 10G/1G SFP+ Ethernet Ports.
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 36
