Citrix ADC MPX
LED Color LED Indicates
OFF No power to any power supply in the
appliance.
Flashing RED No power to this power supply.
Flashing GREEN Power supply is in standby mode.
GREEN Power supply is functional.
RED Power supply failure.
• Disable alarm button, which is functional only when the appliance has two power supplies.
Press this button to silence the power alarm when one of two power supplies loses input power
(second power supply optional) or when a power supply is malfunctioning.
• Non‑Maskable Interrupt (NMI) Button, used at the request of Technical Support to initiate
a core dump. To press this red button, which is recessed to prevent unintentional activation,
use a pen, pencil, or other pointed object. The NMI Button is also available remotely over the
network in the LOM GUI, in the Remote Control menu. For more information about the lights
out management port of the appliance, see Lights out management port of the Citrix ADC MPX
appliance.
Citrix ADC MPX 9700, MPX 10500, MPX 12500, and MPX 15500
September 19, 2022
Note: The non‑FIPS platform has reached its end of life.
The Citrix ADC MPX 9700/10500/12500/15500 are 2U appliances, each with 2 quad‑core processors,
and 16 GB of memory. All these appliances are also available in a 10G model and a FIPS model.
The following figure shows the front panel of the MPX 9700/10500/12500/15500.
Figure 1. Citrix ADC MPX 9700/10500/12500/15500, front panel
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 43
