Citrix ADC MPX
Platform Recommended Version
MPX 16000 2.12.12
MPX 17500 3.39
MPX 17550 3.39
MPX 22000 3.24
MPX 24000 4.08
MPX 25000A 4.14
MPX 25000TA 4.14
MPX 25000‑40G 4.14
MPX 26000 5.03
MPX 26000‑50S 5.03
MPX 26000‑100G
5.03
Configure the network settings on the LOM port
September 19, 2022
The default IP address for initial access to the LOM port is 192.168.1.3. Change the default credentials
and IP address the first time you log on. All LOM GUI operations require you to connect to the appli‑
ance by typing the LOM IP address in a web browser and then entering the administrator credentials.
Alternatively, you can access LOM functionality through the command line by using the ipmitool
utility. Using the ipmitool utility remotely, you can:
• Determine the LOM firmware version number.
• Perform warm and cold restarts.
• Configure LOM network settings.
• Monitor the health of the appliance.
• Perform power control operations.
The utility is available for download at http://ipmitool.sourceforge.net/. The ipmitool utility is also
included in Citrix ADC MPX and CloudBridge/SDX (dom0) appliances for initial LOM port network con‑
figuration. When using the shell, you can choose to use DHCP or static IP settings for initial network
configuration. Aer configuring the network settings, you can use the ipmitool commands over the
network. For example, the BMC firmware revision command would need the same user name, pass‑
word, and IP address that is used to access the BMC/LOM GUI port.
