FreeSpeak Edge | User Guide
Bar color Percentage score
Green over 66%
Yellow between 33 and 66 %
Red below 33%
The percentage score is calculated by an algorithm using Received Signal Strength Indicator
(RSSI), RF activity and the presence of access points.
List view
The following variables can be seen in list view:
l RF channel number (the channel at the top of the list has the best rating)
l % score (0 - 99%)
l RSSI (signal strength 0 - 99%)
l Usage: the amount of RF activity that is detected in this channel
l #AP: the number of wireless access points that use this channel
l SSID (service set identifier (WiFi name) of one of the access points)
Note: Clear-Com recommends that you select channels that have a score above 66% (green).
Note: Once your beltpack is connected to an Edge system, you can check the quality of your
connection to your local transceiver network. Enter the beltpack menu and navigate to:
Diagnostics > Site Survey.
