FreeSpeak Edge | User Guide
Other Indicators
Transceiver state LED Flash rate and color
Read/write activity 1 and 2 flash light blue
Software upgrade in process 1 and 2 flash blue
Software upgrade fail 1 and 2 flash red
Software upgrade succeeded 1 and 2 flash green
Transceiver too cold 1 flashes light blue fast
Transceiver too hot 1 flashes red fast
Hardware failures 2 flashes red fast
Mode indicators
To activate modes, press and hold the mode button for a certain number of seconds.
Press and hold the mode button Mode Feature
Status LED 2 shows mode selection.
< 3 seconds 1 Clear mode selection
> 3 < 6 seconds 2
Identify me feature. LED 2 white for 1
second then color mix flashing
> 6 < 9 seconds 3 LED 2 green. No feature.
> 9 < 12 seconds 4 LED 2 yellow. No feature.
> 12 seconds 5
LED 2 red. Reset the transceiver to
default settings. The device will also
reboot.
7.5 Reset the transceiver to default
To reset the IP Transceiver to default:
1. Press and hold the Mode button for at least 12 seconds. When the transceiver status light
turns red the device will have entered reset mode and you can release the mode button.
This will reset the IP Transceiver and remove any stored diagnostics.
Page 75
