Specification Value
Beltpacks supported per transceiver 10 in one cellular zone
Frequency spectrum
5170 to 5875 (20 MHz channels set by
country)
Transceiver transmission range
l Outdoors 750 ft (230 m) direct line of
sight at maximum output (24 dBm)
l Indoors 250 ft (80 m) at maximum
output (24 dBm)
l Range is influenced by environment
l Reflective surfaces will increase the
range
l Adjustable power settings change
range
l Some 5 GHz channels in certain
countries limit the transmit output (this
limits the range)
Local powering
12VDC power supply or 5V (USB) or 48V
PoE
Output power
Adjustable from 4 to 24 dBm (non sequential
increments). Maximum output power is
determined by the selected channel and
country.
SFP module
1GB (1000Base), <250mA maximum current
draw
Connection to matrix RJ45
Mounting
Separate wall plate with various mounting
options
Mic stand mounts,
Camera spigot mounting hole
Hole for lanyard mounting
Environmental
IP53 water and dust resistance.
Operating: 0 to 45 degrees Celsius
