FreeSpeak Edge | User Guide
Note: Reset can take up to 5 minutes.
l The Admin and the audio (AES67) IP addresses are reset to DHCP
l Channel selection will be reset to the default
l You will need to reconnect the transceiver to the matrix as it will be removed from the
EHX configuration
7.6 Port security settings
The following port security settings apply for the IP Transceiver.
Note: All ports are closed by default, and the firewall is enabled.
Port Setting
AES67 Admin
DHCP (67, 68)
mDNS (5553)
HTTP (80, 8080, 443)
rsync (873)
IVP port is configurable
AES67 Audio
DHCP (67, 68)
PTP (319, 320)
mDNS (5353)
IVP (6001)
HTTP (8080)
7.7 Network and synchronization
The following network and synchronization information applies:
l The transceiver is shipped with DHCP enabled (default). The transceiver supports static
IP addressing, but if you use a static IP you will need to enter two static IP addresses.
l When the transceiver is reset to default it will revert to DHCP mode, and the AES67
Admin interface is set to DHCP.
l When budgeting for network bandwidth be aware that the transceiver will take a
bandwidth of approximately 10 Mbps.
l Be aware that in order to achieve reliable radio sync, your AES67 network requires
tighter PTP sync than most AoIP networks. The IP transceivers have a lower tolerance of
network jitter and delay.
Page 76
