FreeSpeak Edge | User Guide
Orientation of unit Environmental performance
Upright
l Up to 50°c (with 4 inch clearance above and below plus no
heat sources below)
l IP rating 55 (to be confirmed)
Upside down
l Up to 50°c (with 4 inch clearance above and below plus no
heat sources below)
l IP rating not guaranteed
On its side
l Up to 32°c
l No IP rating
Note: For best performance the transceiver should be positioned 6 - 8 feet (1.8 - 2.4 m) above the
floor and 2 feet (0.6 m) below the ceiling.
Note: In areas that have more than one transceiver, the devices should not be less than 10 feet (3 m)
apart. If the transceivers are placed too close together there is a possibility that the
performance of the device will be impaired.
5.2 Clear-Com cable recommendations
Use the following Category (Cat), American Wire Gauge (AWG) and shielded cable types.
Page 28
