CB FALCON
750-265 12
Modulating
Output Signal
22 AWG two-wire twisted
pair, insulated for low voltage
Beldon 8443 or equivalent 50
Modbus
communication
22 AWG two-wire twisted
pair, insulated for low voltage
22 AWG two-wire twisted pair, insulated for low voltage
Temperature
(operating)
Sensors
22 AWG two-wire twisted
pair, insulated for low voltage
Beldon 8443 or equivalent 50
Temperature
(Limit) Sensors
22 AWG two-wire twisted pair
with ground.
Beldon 8723 shielded cable or equivalent 50
Flame Sensor
(Flame Rod/UV)
14, 16, 18 AWG Copper
conductor, 600 volt
insulations, moisture-
resistance wire
TTW60C, THW75C, THHN90C 30
Ignition Ignition Cable rated for 25kV
at 482F(250C)
32004766-001 (2') or -003 (per foot) 3
Grounding Earth ground 1. Earth ground must be capable of conducting enough cur-
rent to blow the 20A fuse (or breaker) in the event of an
internal short circuit.
2. Use wide straps or brackets to provide minimum length,
maximum surface area ground conductors. If a leadwire
must be used, use 14 AWG copper wire.
3. Make sure that mechanically tightened joints along the
ground path are free of nonconductive coatings and pro-
tected against corrosion on mating surfaces.
Grounding Signal ground Use the shield of the signal wire to ground the device to the
signal ground terminals [3(c)] of each device. Connect the
shield at both ends of the chain to earth ground.
Table 2. Wire Sizes. (Continued)
Application Recommended Wire Size Recommended Part Number(s)
Maximum
Leadwire
Distance (in
feet)
