CleaverBrooks CFC-1000 User Manual

Section 2 — Installation
Part No. 750-263 2-9
23.Install rear center panels (Figure 2-15).
24.Install C-clips on upper side panels, then install panels on boiler (Figure
2-16).
25.Install top rear panel and top center panel.
26.Attach side skirt panels to boiler legs using the supplied cap nuts (Figure
2-17).
Figure 2-14
Figure 2-15
Figure 2-16
