CleaverBrooks CFC-1000 User Manual

Section 4 — CFC Commissioning
4-10 Part No. 750-263
Pump Configuration Boiler pump options 2 Service 0xC0DF 0301
Pump Configuration System pump options 1 Service 0xE36C 0302
Pump Configuration System pump options 2 Service 0x801D 0303
Pump Configuration
Auxiliary 1 pump overrun
time Service 0 300 28800 seconds 0752
Pump Configuration Auxiliary 1 pump options 1 Service 0x0003 0753
Pump Configuration Auxiliary 1 pump options 2 Service 0x4002 0754
Pump Configuration Auxiliary 2 pump output Service Pump C 0755
Pump Configuration Auxiliary 2 pump control Service Auto 0756
Pump Configuration Auxiliary 2 pump start delay Service 0 0 28800 seconds 0757
Pump Configuration
Auxiliary 2 pump overrun
time Service 0 0 28800 seconds 0758
Pump Configuration Auxiliary 2 pump options 1 Service 0x0000 0759
Pump Configuration Auxiliary 2 pump options 2 Service 0x4001 0760
Statistics Configuration Burner cycle count Read Only 0 999,999 0128
Statistics Configuration Burner run time Read Only 0 999,999 0130
Statistics Configuration CH pump cycle count Read Only 0 999,999 0132
Statistics Configuration DHW pump cycle count Read Only 0 999,999 0134
Statistics Configuration System pump cycle count Read Only 0 999,999 0136
Statistics Configuration Boiler pump cycle count Read Only 0 999,999 0138
Statistics Configuration Auxiliary 1 pump cycle count Read Only 0 999,999 0140
Statistics Configuration Auxiliary 2 pump cycle count Read Only 0 999,999 0146
System Configuration Temperature units Service Fahrenheit 0178
System Configuration Antishort cycle time Service 0 60 28800 seconds 0179
System Configuration Alarm silence time Service 0 0 3600 seconds 0180
System Configuration Power-up with lockout Read Only Do NOT clear lockout 0181
System Configuration Burner switch User Off 0203
System Configuration Blower/HSI function Read Only Blower 0225
System Configuration Flame sensor type OEM Flame rod 0228
System Configuration Forced recycle interval time Service 0 seconds 0254
System Configuration Fan speed error response Service Lockout 0255
System (Sensor) Configuration Inlet sensor type Read Only
10k NTC single non-
safety
608
System (Sensor) Configuration
S2 (remote 4-20mA or
header) sensor type
OEM 4-20mA 609
System (Sensor) Configuration Outlet sensor type Read Only 10k NTC dual safety 610
System (Sensor) Configuration S5 (outdoor) sensor type Service
10k NTC single non-
safety
611
System (Sensor) Configuration DHW sensor type Service
10k NTC single non-
safety
612
System (Sensor) Configuration Stack sensor type Service Unconfigured 613
System (Sensor) Configuration Outdoor temperature source Service Unconfigured 626
System Configuration
Warm weather shutdown
enable
Service
Warm weather
shutdown disabled
0627
System Configuration
Warm weather shutdown
setpoint
Service 100 °F 0628
System Configuration
Use STAT with EnviraCOM
remote stat
Hidden Disable 0629
Fan Configuration Absolute max. fan speed OEM 2000 6000 6500 RPM 0256
Fan Configuration Absolute min. fan speed OEM 800 800 3000 RPM 0257
Fan Configuration PWM frequency OEM 1000 3000 4000 Hz 0258
Fan Configuration Pulses per revolution Read Only 2 3 3 0259
Table 4-1 CFC default parameter settings
Parameter Group Parameter Name Access*
Min.
Range Default Setting
Max.
Range
Parameter
Units Installation Setting
Modbus
Register
(dec)
