Plate HX Preheat Plate preheat OFF hysteresis Service 5 °F
not used
0692
Plate HX Preheat
Plate preheat minimum on
time Service 60 seconds
not used
0693
Plate HX Preheat
Tap detect degrees per
second Service 2 °F
not used
0694
Plate HX Preheat Tap detect ON hysteresis Service 20 °F not used 0695
Plate HX Preheat
Tap detect on recognition
time Service 5 seconds not used 0696
Plate HX Preheat Tap stop Inlet-DHW degrees Service 5 °F
not used
0697
Plate HX Preheat
Tap stop Outlet-DHW
degrees Service 10 °F
not used
0698
Plate HX Preheat Tap detect minimum on time Service 60 seconds not used 0699
Plate HX Preheat Tap detect on threshold Service No value °F
not used
0700
Plate HX Preheat
Plate preheat detect on
threshold Service No value °F not used 0701
Plate HX Preheat
Plate preheat detect off
threshold Service No value °F not used 0702
Annunciation Configuration Annunciation enable Hidden Enabled 0304
Annunciation Configuration Annunciator 1 location OEM Other 0306
Annunciation Configuration Annunciator 1 short name OEM A1 0307
Annunciation Configuration Annunciator 1 long name OEM AIR SWITCH 0309
Annunciation Configuration Annunciator 2 location Service Unused (or LCI) 0319
Annunciation Configuration Annunciator 2 short name Service A2 0320
Annunciation Configuration Annunciator 2 long name Service AUX LOW WATER 0322
Annunciation Configuration Annunciator 3 location OEM ILK 0332
Annunciation Configuration Annunciator 3 short name OEM A3 0333
Annunciation Configuration Annunciator 3 long name OEM LOW WATER 0335
Annunciation Configuration Annunciator 4 location OEM ILK 0345
Annunciation Configuration Annunciator 4 short name OEM A4 0346
Annunciation Configuration Annunciator 4 long name OEM HIGH AIR PRESSURE 0348
Annunciation Configuration Annunciator 5 location OEM ILK 0358
Annunciation Configuration Annunciator 5 short name OEM A5 0359
Annunciation Configuration Annunciator 5 long name OEM
HIGH GAS
PRESSURE 0361
Annunciation Configuration Annunciator 6 location OEM ILK 0371
Annunciation Configuration Annunciator 6 short name OEM A6 0372
Annunciation Configuration Annunciator 6 long name OEM LOW GAS PRESSURE 0374
Annunciation Configuration Annunciator 7 location Service ILK 0384
Annunciation Configuration Annunciator 7 short name Service A7 0385
Annunciation Configuration Annunciator 7 long name Service NATURAL GAS 0387
Annunciation Configuration Annunciator 8 location Service ILK 0397
Annunciation Configuration Annunciator 8 short name Service A8 0398
Annunciation Configuration Annunciator 8 long name Service LP GAS 0400
Annunciation Configuration PII short name OEM PII 0410
Annunciation Configuration PII long name OEM Pre-Ignition ILK 0412
Annunciation Configuration LCI short name OEM LCI 0422
Annunciation Configuration LCI long name OEM Load Control Input 0424
Annunciation Configuration ILK short name OEM ILK 0434
Annunciation Configuration ILK long name OEM Interlock 0436
Anti-condensation Configuration CH anti-condensation enable Service Disabled 0496
Anti-condensation Configuration
CH anti-condensation
setpoint Service 32 140 194 °F 0497
Table 4-1 CFC default parameter settings
Parameter Group Parameter Name Access*
Min.
Range Default Setting
Max.
Range
Parameter
Units Installation Setting
Modbus
Register
(dec)
