Section 4 — CFC Commissioning
4-14 Part No. 750-263
*Access Levels:
Read Only = parameter not configurable
OEM = manufacturer only
Service = password required (default password is 9220)
User = no password required
Lead Lag Configuration
Lead Lag add stage
detection time 1 Service 60 300 seconds 0716
Lead Lag Configuration
Lead Lag add stage error
threshold Service 5 °F 0718
Lead Lag Configuration
Lead Lag add stage rate
offset Service -100 20% 100 % 0719
Lead Lag Configuration
Lead Lag add stage
interstage delay Service 180 900 seconds 0722
Lead Lag Configuration
Lead Lag drop stage method
1 Service Firing rate threshold 0723
Lead Lag Configuration
Lead Lag drop stage
detection time 1 Service 60 300 seconds 0725
Lead Lag Configuration
Lead Lag drop stage error
threshold Service 10 °F 0727
Lead Lag Configuration
Lead Lag drop stage rate
offset Service -100 -3% 100
%
0728
Lead Lag Configuration
Lead Lag drop stage
interstage delay Service 180 900 seconds 0731
Lead Lag Configuration Lead rotation time Service 1 24 hours 0733
Lead Lag Configuration Force lead rotation time Service 1 168 hours 0734
Lead Lag Configuration Boiler off options Service
All Boilers Off option
disabled
0736
Lead Lag Configuration All boilers off threshold Service 25 °F 0737
Lead Lag Configuration
Lead Lag CH ODR min.
outdoor temperature Service -40 0 140 °F 0518
Lead Lag Configuration
Lead Lag CH ODR low water
temperature Service 80 180 °F 0519
Lead Lag Configuration
Lead Lag CH ODR maximum
off point Service 32 194 230 °F 0521
Lead Lag Configuration
Lead Lag CH ODR min.
water temperature Service 80 230 °F 0527
Lead Lag Configuration
Lead Lag CH outdoor reset
enable Service Disabled 0548
Shaded parameters are Safety Parameters and require Verification and manual reset of the control prior to operation. Please refer to Section A, "Changing
parameter settings".
Table 4-1 CFC default parameter settings
Parameter Group Parameter Name Access*
Min.
Range Default Setting
Max.
Range
Parameter
Units Installation Setting
Modbus
Register
(dec)
