Electrical Data – Standard Unit
Table 4: Electrical Data - Standard Units
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/
MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G 208-230 / 60 / 1 187.2 / 253 1 2.6 17.7 0.3 2.9 3.6 15
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 0.4 3.0 3.6 15
009
G 208-230 / 60 / 1 187.2 / 253 1 3.7 22 0.8 4.5 5.5 15
E 265 / 60 / 1 238.5 / 291.5 1 3.4 17.5 0.8 4.2 5.1 15
012
G 208-230 / 60 / 1 187.2 / 253 1 5.6 32.5 0.8 6.4 7.8 15
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 0.8 5.0 6.1 15
015
G 208-230 / 60 / 1 187.2 / 253 1 5.6 29.0 0.9 6.5 7.9 15
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28.0 0.7 5.7 7.0 15
018
G 208-230 / 60 / 1 187.2 / 253 1 7.4 33.0 0.9 8.3 10.2 15
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28.0 0.7 6.7 8.2 15
024
G 208-230 / 60 / 1 187.2 / 253 1 12.8 58.3 1.5 14.3 17.5 30
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54.0 1.2 10.8 13.2 20
F 460 / 60 / 3 414 / 506 1 3.6 28.0 1.4 5.0 5.9 15
H 208-230 / 60 / 3 187.2 / 253 1 7.7 55.4 1.5 9.2 11.1 15
030
G 208-230 / 60 / 1 187.2 / 253 1 14.1 73.0 2.7 16.8 20.3 30
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60.0 2.9 14.1 16.9 25
F 460 / 60 / 3 414 / 506 1 4.2 28.0 1.6 5.8 6.9 15
H 208-230 / 60 / 3 187.2 / 253 1 8.9 58.0 2.7 11.6 13.8 20
036
G 208-230 / 60 / 1 187.2 / 253 1 16.7 79.0 2.7 19.4 23.5 40
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72.0 2.0 15.5 18.9 30
F 460 / 60 / 3 414 / 506 1 5.8 38.0 1.2 7.0 8.5 15
H 208-230 / 60 / 3 187.2 / 253 1 10.4 73.0 2.7 13.1 15.7 25
041*
G 208-230 / 60 / 1 187.2 / 253 1 17.9 112.0 2.7 20.6 25.1 40
F 460 / 60 / 3 414 / 506 1 6.0 44.0 1.6 7.6 9.1 15
H 208-230 / 60 / 3 187.2 / 253 1 13.2 88.0 2.7 15.9 19.2 30
N 575 / 60 / 3 517.5 / 632.5 1 4.2 30.0 1.
4 5.6 6.7 15
042
G 208-230 / 60 / 1 187.2 / 253 1 17.9 112.0 2.7 20.6 25.1 40
F 460 / 60 / 3 414 / 506 1 6.0 44.0 1.6 7.6 9.1 15
H 208-230 / 60 / 3 187.2 / 253 1 13.5 88.0 2.7 16.2 19.6 30
N 575 / 60 / 3 517.5 / 632.5 1 4.9 34.0 1.4 6.3 7.5 15
048
G 208-230 / 60 / 1 187.2 / 253 1 21.8 117.0 3.3 25.1 30.6 50
F 460 / 60 / 3 414 / 506 1 6.2 41.0 1.7 7.9 9.5 15
H 208-230 / 60 / 3 187.2 / 253 1 13.7 83.1 3.3 17.0 20.4 30
N 575 / 60 / 3 517.5 / 632.5 1 4.8 33.0 1.4 6.2 7.4 15
060
G 208-230 / 60 / 1 187.2 / 253 1 26.3 134.0 4.8 31.1 37.7 60
F 460 / 60 / 3 414 / 506 1 7.8 52.0 2.4 10.2 12.2 15
H 208-230 / 60 / 3 187.2 / 253 1 15.6 110.0 4.8 20.4 24.3 40
N 575 / 60 / 3 517.5 / 632.5 1 5.8 38.9 1.8 7.6 9.1 15
* 460 volt units require a neutral connection. All “F” voltage units with constant volume ECM require a four wire power supply with neutral.
Motors are 265 volt and are wired between one hot leg and neutral.
All fuses Class RK-5
