Unit Operating Conditions
Table 9: TC Coax Water Pressure Drop
Model
U.S.
GPM
l/s
Pressure Drop, psi [kPa]*
30°F [-1°C] 50°F [10°C] 70°F [21°C] 90°F [32°C]
006
0.75 0.05 0.5 [3.7] 0.3 [2.3] 0.2 [1.6] 0.2 [1.6]
1.1 0.07 0.8 [5.3] 0.5 [3.5] 0.4 [2.7] 0.3 [2.2]
1.5 0.09 1.3 [8.8] 0.9 [6.1] 0.7 [4.8] 0.6 [4.0]
009
1.1 0.07 1.3 [9.0] 0.6 [4.4] 0.4 [2.8] 0.3 [1.9]
1.8 0.11 2.1 [14.1] 1.4 [9.4] 1.1 [7.4] 0.9 [6.2]
2.3 0.14 3.5 [24.3] 2.6 [17.9] 2.1 [14.7] 1.8 [12.7]
012
1.5 0.09 1.9 [12.8] 1.1 [7.6] 0.8 [5.3] 0.6 [4.1]
2.3 0.15 3.6 [25.0] 2.6 [17.8] 2.1 [14.3] 1.8 [12.1]
3.0 0.19 6.7 [46.1] 5.0 [34.3] 4.1 [28.3] 3.6 [24.5]
015
1.9 0.12 1.0 [6.9] 0.6 [4.4] 0.5 [3.4] 0.4 [2.8]
2.8 0.18 1.8 [12.4] 1.4 [9.3] 1.1 [7.6] 1.0 [6.9]
3.8 0.24 3.3 [22.7] 2.5 [17.5] 2.1 [14.7] 1.9 [13.1]
018
2.3 0.14 2.1 [14.5] 1.4 [9.9] 1.1 [7.6] 0.9 [6.2]
3.4 0.21 3.4 [23.4] 2.6 [17.6] 2.1 [14.7] 1.8 [12.4]
4.5 0.28 5.9 [40.6] 4.6 [31.5] 3.9 [26.9] 3.4 [23.4]
024
3.0 0.19 2.2 [15.2] 1.7 [11.6] 1.4 [9.6] 1.2 [8.3]
4.5 0.28 4.0 [27.6] 3.2 [22.2] 2.8 [19.3] 2.5 [17.2]
6.0 0.38 7.2 [49.6] 5.9 [40.6] 5.2 [35.8] 4.7 [32.4]
030
3.8 0.24 1.3 [9.0] 0.9 [6.1] 0.7 [4.8] 0.6 [4.1]
5.6 0.35 2.3 [15.8] 1.8 [12.5] 1.5 [10.3] 1.4 [9.6]
7.5 0.47 4.2 [28.9] 3.4 [23.2] 2.9 [20] 2.6 [17.9]
036
4.5 0.28 1.8 [12.4] 1.4 [9.6] 1.2 [8.3] 1.0 [6.9]
6.8 0.43 3.1 [21.4] 2.4 [16.8] 2.1 [14.7] 1.9 [13.1]
9.0 0.57 5.4 [37.2] 4.4 [30.0] 3.8 [26.2] 3.4 [23.4]
041
5.0 0.32 2.2 [15.0] 1.6 [10.8] 1.1 [7.7] 0.8 [5.6]
7.5 0.47 4.6 [32.0] 3.5 [24.0] 2.6 [18.01] 2.1 [14.5]
10.0 0.63 7.7 [53.3] 6.1 [42.1] 5.1 [34.8] 4.6 [31.4]
042
5.3 0.33 2.3 [15.8] 1.8 [12.1] 1.5 [10.3] 1.3 [9.0]
7.9 0.50 4.3 [29.6] 3.5 [24.2] 3.1 [26.4] 2.8 [19.3]
10.5 0.66 7.9 [54.4] 6.5 [44.8] 5.7 [39.3] 5.2 [35.8]
048
6.0 .038 1.8 [12.4] 1.5 [10.1] 1.3 [9.0] 1.2 [8.3]
9.0 0.57 3.4 [23.4] 3.0 [20.4] 2.7 [18.6] 2.6 [17.9]
12.0 0.76 6.2 [42.7] 5.5 [37.9] 5.1 [35.1] 4.8 [35.1]
060
7.5 0.47 3.4 [23.4] 2.8 [19.2] 2.4 [16.5] 2.2 [15.2]
11.3 0.71 6.8 [46.9] 5.9 [40.8] 5.4 [37.2] 5.0 [34.5]
15.0 0.95 12.6 [86.8] 11.1 [76.8] 10.3 [71.0] 9.6 [66.1]
