ClimateMaster Tranquility TCH 024 - Blower Performance Data - TC012

ClimateMaster Water-Source Heat Pumps
40
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
Blower Performance Data – TC012
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
380 300 PSC
Low CFM 360 350 320 310
Medium CFM 420 400 380 360 340
High CFM 470 450 430 400 380 320
380 300
ECM -
Constant
Torque
1
RPM 1338 1385 1436 1491 1551 1623 1688 1748 1800 1828
Power (W) 64 66 69 71 75 78 82 85 87 83
CFM 358 345 332 319 305 291 275 261 247 218
2
RPM 1477 1517 1561 1612 1660 1711 1769 1819 1841 1858
Power (W) 86 88 91 94 97 100 103 104 97 91
CFM 400 388 377 365 354 342 328 309 269 237
3
RPM 1632 1672 1709 1747 1785 1820 1835 1856 1850 1858
Power (W) 116 119 122 124 126 126 121 114 99 91
CFM 449 437 427 414 401 385 359 327 274 238
4
RPM 1698 1729 1765 1798 1821 1836 1842 1843 1850 1864
Power (W) 131 133 135 137 135 130 123 110 99 92
CFM 467 456 444 433 414 390 361 318 273 239
380 300
ECM -
Constant
Volume
Minimum CFM
RPM 1258 1368 1464 1555 1635 1718 1793 1830
Power (W) 55 64 73 81 90 99 107 106
CFM 300 300 300 300 300 300 300 300
Default CFM
RPM 1598 1672 1743 1813 1831 1845 1859 1875
Power (W) 105 115 125 135 132 127 123 118
CFM 380 380 380 380 380 380 380 380
Maximum CFM
RPM 1798 1823 1834 1844 1858 1872 1886 1901 1920
Power (W) 147 149 146 143 139 134 130 126 120
CFM 415 415 415 415 415 415 415 415 415
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
