ClimateMaster Tranquility TCH 024 - Unit Physical Data

ClimateMaster Water-Source Heat Pumps
6
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
Unit Physical Data
Tranquility
®
16 (TC) Series (60 Hz)
TC Series 006 009 012 015 018 024 030 036 041 042 048 060
Compressor (1 Each) Rotary Scroll
Factory Charge
HFC-410A (oz)
19 20 23 35 43 40 48 50 70 70 74 82
ECM Fan Motor & Blower
Blower Wheel Size
(Dia x w)
6x5 6x5 6x5 9x7 9x7 9x7 9x7 9x8 N/A 9x8 10x10 12x10
PSC Fan Motor & Blower
Fan Motor Type/Speeds PSC/3 PSC/3 PSC-3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3
Blower Wheel Size
(Dia x w)
5x5 5x5 6x5 8x7 8x7 9x7 9x7 9x8 9x8 9x8 10x10 12x10
Water Connection Size
FPT 1/2” 1/2” 1/2” 1/2" 1/2" 3/4" 3/4" 3/4" 3/4” 3/4" 1" 1"
Coax Volume (gallons) 0.123 0.143 0.167 0.286 0.450 0.286 0.323 0.323 0.890 0.890 0.738 0.939
Vertical
Air Coil Dimensions
(H x W)
10x15 10x15 10x15 20x17.25 20x17.25 20x17.25 20x17.25 24x21.75 20x17.25 24x21.76 24x28.25 24x28.25
Filter Standard - 1"
Throwaway
10x18 10x18 10x18 20x20 20x20 20x20 20x20 24x24 20x20 24x24
1-14x24,
1-18x24
1-14x24,
1-18x24
Weight - Operating (lbs.) 103 105 114 153 158 189 197 203 210 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 194 202 209 217 224 270
285
Horizontal
Air Coil Dimensions
(H x W)
10x15 10x15 10x15 16x22 16x22 16x22 16x22 20x25 N/A 20x25 20x35 20x35
Filter Standard - 1"
Throwaway
10x18 10x18 10x18 16x25 16x25 18x25 18x25
20x28 or
2-20x14
N/A
20x28 or
2-20x14
1-20x24,
1-20x14
1-20x24,
1-20x14
Weight - Operating (lbs.) 103 105 114 153 158 174 182 203 N/A 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 179 187 209 N/A 224 270 285
Notes:
All units have TXV expansion device, and 1/2” & 3/4” electrical knockouts.
FPT = Female Pipe Thread
Condensate Drain Connection is 3/4” FPT.
575 volt fan motors are two speed.
Models 006, 009, 012 compressor are mounted on springs. Installer must loosen bolts and remove shipping bracket.
Unit Maximum Water Working Pressure
Max Pressure PSIG
[kPa]
Base Unit 500 [3447]
WSE Option 300 [2068]
