Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Blower Performance Data – TC009
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
325 225 PSC
Low CFM 340 322 300 260
Medium CFM 390 360 320 290 260
High CFM 410 380 350 320 280
325 225
ECM -
Constant
Torque
1
RPM 1137 1203 1266 1344 1413
Power (W) 40 42 44 47 49
CFM 294 278 259 245 230
2
RPM 1361 1413 1464 1503 1577 1640 1700 1751 1803 1831
Power (W) 67 70 73 74 79 82 85 88 90 85
CFM 370 357 343 326 318 302 291 278 265 235
3
RPM 1538 1589 1642 1695 1749 1812 1829 1847
Power (W) 86 88 91 95 98 101 96 90
CFM 370 358 346 334 322 307 280 247
4
RPM 1835 1853 1869 1875
Power (W) 120 113 107 102
CFM 340 309 276 234
325 225
ECM -
Constant
Volume
Minimum CFM
RPM 929 1083 1210 1324 1432 1529 1595 1723 1792
Power (W) 25 32 39 45 53 60 66 78 83
CFM 225 225 225 225 225 225 225 225 225
Default CFM
RPM 1209 1326 1430 1535 1635 1732 1792 1801 1811
Power (W) 49 58 67 77 88 100 105 95 88
CFM 325 325 325 325 325 325 325 325 325
Maximum CFM
RPM 1691 1753 1765 1769 1778 1784 1793 1803 1813
Power (W) 126 134 131 125 119 118 105 98 90
CFM 375 375 375 375 375 375 375 375 375
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
