Electrical Data – High Static Blower
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/
MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
015
G 208-230 / 60 / 1 187.2 / 253 1 5.6 29.0 0.9 6.5 7.9 15
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28.0 0.7 5.7 7.0 15
018
G 208-230 / 60 / 1 187.2 / 253 1 7.4 33.0 0.9 8.3 10.2 15
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28.0 0.7 6.7 8.2 15
024
G 208-230 / 60 / 1 187.2 / 253 1 12.8 58.3 2.7 15.5 18.7 30
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54.0 2.9 12.5 14.9 20
F 460 / 60 / 3 414 / 506 1 3.6 28.0 1.6 5.2 6.1 15
H 208-230 / 60 / 3 187.2 / 253 1 7.7 55.4 2.7 10.4 12.3 20
030
G 208-230 / 60 / 1 187.2 / 253 1 14.1 73.0 2.7 16.8 20.3 30
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60.0 2.9 14.1 16.9 25
F 460 / 60 / 3 414 / 506 1 4.2 28.0 1.6 5.8 6.9 15
H 208-230 / 60 / 3 187.2 / 253 1 8.9 58.0 2.7 11.6 13.8 20
036
G 208-230 / 60 /
1 187.2 / 253 1 16.7 79.0 2.7 19.4 23.6 40
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72.0 2.9 16.4 19.8 30
F 460 / 60 / 3 414 / 506 1 5.8 38.0 1.6 7.4 8.9 15
H 208-230 / 60 / 3 187.2 / 253 1 10.4 73.0 2.7 13.1 15.7 25
042
G 208-230 / 60 / 1 187.2 / 253 1 17.9 112.0 2.7 20.6 25.1 40
F 460 / 60 / 3 414 / 506 1 6.0 44.0 1.6 7.6 9.1 15
H 208-230 / 60 / 3 187.2 / 253 1 13.5 88.0 2.7 16.2 19.6 30
N 575 / 60 / 3 517.5 / 632.5 1 4.9 34.0 1.4 6.3 7.5 15
048
G 208-230 / 60 / 1 187.2 / 253 1 21.8 117.0 4.8 26.6 32.1 50
F 460 / 60 / 3 414 / 506 1 6.2 41.0 2.4 8.6 10.2 15
H 208-230 / 60 / 3 187.2 / 253 1 13.7 83.1 4.8 18.5 21.9 35
N 575 / 60 / 3 517.5 / 632.5 1 4.8 33.0 1.8 6.6 7.8 15
060
G 208-230 / 60 / 1 187.2 / 253 1 26.3 134.0 5.7 32.0 38.6 60
F 460 / 60 / 3 414 / 506 1 7.8 52.0 2.5 10.3 12.3 20
H 208-230 / 60 / 3 187.2 / 253 1 15.6 110.0 5.7 21.3 25.2 40
N 575 / 60 / 3 517.5 / 632.5 1 5.8 38.9 1.9 7.7 9.2 15
* 460 volt units require a neutral connection. All “F” voltage units with constant volume ECM require a four wire power supply with neutral.
Motors are 265 volt and are wired between one hot leg and neutral.
All fuses Class RK-5
