ClimateMaster Tranquility TCH 024 - Electrical Data - Constant Torque ECM

ClimateMaster Water-Source Heat Pumps
32
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
Electrical Data – Constant Torque ECM
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/
MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G 208-230 / 60 / 1 187.2 / 253 1 2.6 17.7 2.3 4.9 5.6 15
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 2.3 4.9 5.6 15
009
G 208-230 / 60 / 1 187.2 / 253 1 3.7 22.2 2.3 6.0 6.9 15
E 265 / 60 / 1 238.5 / 291.5 1 3.4 18.8 2.3 5.7 6.6 15
012
G 208-230 / 60 / 1 187.2 / 253 1 5.6 32.5 2.3 7.9 9.3 15
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 2.3 6.5 7.6 15
015
G 208-230 / 60 / 1 187.2 / 253 1 5.6 29.0 2.6 8.2 9.6 15
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28.0 1.9 6.9 8.2 15
018
G 208-230 / 60 / 1 187.2 / 253 1 7.4 33.0 2.6 10.0 11.9 15
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28.0 1.9 7.9 9.4 15
024
G 208-230 / 60 / 1 187.2 / 253 1 12.8 58.3 3.9 16.7 19.9 30
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54.0 3.2 12.8 15.
2 20
F 460 / 60 / 3 414 / 506 1 3.6 28.0 1.1 4.7 5.6 15
H 208-230 / 60 / 3 187.2 / 253 1 7.7 55.4 3.9 11.6 13.5 20
030
G 208-230 / 60 / 1 187.2 / 253 1 14.1 73.0 3.9 18.0 21.5 35
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60.0 3.2 14.4 17.2 25
F 460 / 60 / 3 414 / 506 1 4.2 28.0 1.1 5.3 6.4 15
H 208-230 / 60 / 3 187.2 / 253 1 8.9 58.0 3.9 12.8 15.0 20
036
G 208-230 / 60 / 1 187.2 / 253 1 16.7 79.0 6.0 22.7 26.9 40
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72.0 3.9 17.4 20.8 30
F 460 / 60 / 3 414 / 506 1 5.8 38.0 1.5 7.3 8.8 15
H 208-230 / 60 / 3 187.2 / 253 1 10.4 73.0 6.0 16.4 19.0 25
042
G 208-230 / 60 / 1 187.2 / 253 1 17.9 112.0 6.0 23.9 28.4 45
F 460 / 60 / 3 414 / 506 1 6.0 44.0 1.5 7.5 9.0 15
H 208-230 / 60 / 3 187.2 / 253 1 13.5 88.0 6.0 19.5 22.9 35
048
G 208-230 / 60 / 1 187.2 / 253 1 21.8 117.0
7.5 29.3 34.8 50
F 460 / 60 / 3 414 / 506 1 6.2 41.0 2.1 8.3 9.9 15
H 208-230 / 60 / 3 187.2 / 253 1 13.7 83.1 7.5 21.2 24.6 35
060
G 208-230 / 60 / 1 187.2 / 253 1 26.3 134.0 7.5 33.8 40.4 60
F 460 / 60 / 3 414 / 506 1 7.8 52.0 2.1 9.9 11.9 15
H 208-230 / 60 / 3 187.2 / 253 1 15.6 110.0 7.5 23.1 27.0 40
* 460 volt units require a neutral connection. All “F” voltage units with constant volume ECM require a four wire power supply with neutral.
Motors are 265 volt and are wired between one hot leg and neutral.
All fuses Class RK-5
