ClimateMaster Tranquility TCH 024 - Blower Performance Data - TC048

ClimateMaster Water-Source Heat Pumps
48
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
Blower Performance Data – TC048
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1600 1200 PSC
Low CFM 1644 1606 1568 1492 1378 1264
Medium CFM 1805 1767 1682 1625 1520 1340
High CFM 1881 1815 1710 1596 1416 1216 1216
1600 1200
PSC -
High
Static
Low CFM 1748 1720 1691 1644 1587 1520 1435 1311
Medium CFM 1938 1891 1843 1796 1739 1691 1625 1539 1416 1254
High CFM 1957 1910 1862 1786 1701 1577 1435
1500 1200
ECM -
Constant
Torque
1
RPM 767 811 848 886 935
Power (W) 225 237 247 257 270
CFM 1397 1349 1304 1259 1202
2
RPM 826 869 905 940 979 1026 1073
Power (W) 287 300 312 322 334 349 363
CFM 1527 1484 1441 1398 1351 1294 1240
3
RPM 881 925 960 993 1027 1064 1108 1150 1214
Power (W) 358 374 387 398 410 423 439 454 473
CFM 1660 1619 1577 1537 1494 1452 1399 1349 1254
4
RPM 959 997 1034 1064 1093 1124 1157 1195 1206
Power (W) 474 491 507 521 533 546 560 576 511
CFM 1837 1795 1760 1722 1685 1647 1608 1560 1382
5
RPM 1078 1113 1145 1174 1200 1213 1200
Power (W) 649 667 684 698 714 695 588
CFM 1993 1956 1919 1886 1854 1784 1588
1500 1200
ECM -
Constant
Volume
Minimum CFM
RPM 703 766 827 886 943 998 1051 1102 1150 1196
Power (W) 174 205 237 269 302 336 371 407 444 482
CFM 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Default CFM
RPM 833 884 932 986 1043 1089 1137 1191 1242 1293
Power (W) 287 329 369 412 455 495 536 578 620 662
CFM 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
Maximum CFM
RPM 993 1038 1082 1129 1178 1220 1264 1311 1357 1402
Power (W) 562 616 669 724 781 832 885 940 994 1048
CFM 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
